Type: 1000 W short-arc discharge
Color temperature: 6000
KCRI (Color rendering index): >95
Average lifetime: 750 hours
Socket: PGJX36Ballast: Electronic
Approved lamps: Osram Lok-it! 1000/PS Brilliant,
Philips MSR Gold MiniFastFit 1000W
Zoom range: 10-44° (1:4)Output: 26 000 lm
Fixture identification: User-settable fixture ID numberColor(s): Black
Housing: UV-resistant fiber-reinforced composite
Reflector: Glass, cold lightProtection rating: IP20
Size: E27 (Size E, max. image diameter 27 mm)
Approved material: Borosilicate 3.3 or better with dichroic or
heavy matted alcoating (metal gobos not approved)
Outside diameter: 37.5 mm +0/- 0.2 mm (1.5 in. +0/- 0.01 in.)Maximum image diameter: 27 mm (1.1 in.)
Maximum thickness: 1.1 mm +/- 0.1 mm (0.1 in. +/- 0.01 in.)
Mounting points: Eight quarter-turn locking pointsOrientation: Any
Minimum distance to illuminated surfaces: 3.4 m (11.2 ft.)
Minimum distance to combustible materials: 0.3 m (1.0 ft.)AC power input: Neutrik PowerCon
DMX and RDM data in/out:3-pin locking XLR
USB memory devices: USB host socketAC power: 120-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Typical half-cycle RMS inrush current: 16.2A
